| Model name |
Indoor Unit |
DJ35VE0BG |
| Outdoor Unit |
DJ35VE0BW |
| Model code |
Indoor Unit |
20000958 |
| Outdoor Unit |
20000957 |
| Cooling Capacity |
W |
3500 (1200 - 4100) |
| Rated Input-Cooling |
W |
1000 (190 - 1500) |
| Rated Current Cooling |
A |
4.4 |
| Heating Capacity |
W |
4000 (1600 - 4300) |
| Rated Input-Heating |
W |
1025 (190 - 1500) |
| Rated Current Heating |
A |
4.5 |
| Voltage, Frequency, Phase |
V - Hz - Ph |
220 - 240V~50Hz~1P |
| SEER |
Cooling |
6.1 |
| SCOP |
Heating |
4 |
| Energy Class |
Cooling |
A++ |
| Energy Class |
Heating |
A+ |
| Moisture Removal |
L/hour |
1.2 |
| Air flow |
| Air Circulation |
m3/h |
600 |
| Noise power/pressure |
| Indoor Unit Noise Level - Sound Pressure |
dB (A) |
56 |
| Indoor Unit Noise Level - Sound Power |
dB (A) |
40/38/36/34/31/28 |
| Outdoor Unit Noise Level - Sound Pressure |
dB (A) |
63 |
| Outdoor Unit Noise Level - Sound Power |
dB (A) |
54 |
| Refrigerant |
| Refrigerant |
/ |
R32 |
| Refrigerant charge volume |
g |
760 |
| Connecting Pipe Diameter |
| Liquid Pipe |
inch (mm) |
1/4 (6.35) |
| Gas Pipe |
inch (mm) |
3/8 (9.52) |
| Max length of pipe |
m |
15 |
| Max height difference |
m |
10 |
| Dimensions |
| Net Dimensions - Indoor Unit |
mm (WxHxD) |
815×270×212 |
| Net Dimensions - Outdoor Unit |
mm (WxHxD) |
715×240×482 |
| Net Weight - Indoor Unit |
kg |
8.5 |
| Net Weight - Outdoor Unit |
kg |
27 |
| Packing Dimensions - Indoor Unit |
mm (WxHxD) |
870×335×265 |
| Packing Dimensions - Outdoor Unit |
mm (WxHxD) |
830×315×530 |
| Gross Weight - Indoor Unit |
kg |
10.5 |
| Gross Weight - Outdoor Unit |
kg |
30 |
| Loading Capacity (20’/40’/40’HC ) No Pipe |
sets |
140/283/320 |
| Operating temperature |
| Operating Temp Range |
Cooling (°C) |
- 15 °C - 43 °C |
| Heating (°C) |
- 15 °C - 24 °C |
| Useful area |
| Max. useful area* |
24 |
